General data:
Type: Electronic Intelligence (ELINT) Crew: 2
Min Speed: 350 kt Max Speed: 750 kt
Wingspan: 17.6 m Height: 6.2 m
Length: 24.6 m Max Payload: 8100 kg
Empty Weight: 21150 kg Max Weight: 39570 kg
Operator: Frontal Aviation [VVS] Commissioned: 1990
Propulsion: 2x AL-21F-3A Decommissioned: 1991
Sensors / EW:
SPS-22/33/44/55 Buket [OECM] - (Su-24MP, An-12PP) ECM
OECM, Offensive ECM
Max Range: 0 km
Drop Kick [RPO Orion-A] - (Su-24M) Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Medium-Range
Max Range: 148.2 km
SPS-5 Fasol [OECM] - (Su-24MP) ECM
OECM, Offensive ECM
Max Range: 0 km
L-082 Mak-UL - (BKO-2 Karpaty EW Suite) Infrared
MAWS, Missile Approach Warning System
Max Range: 9.3 km
SPS-162 Geran-F [L-102] - (Su-24M, BKO-2 Karpaty EW Suite) ECM
DECM, Defensive ECM
Max Range: 0 km
SPS-5 Fasol [ESM] - (Su-24MP) ESM
ELINT
Max Range: 926 km
SPS-22/33/44/55 Buket [ESM] - (Su-24MP, An-12PP) ESM
ELINT
Max Range: 926 km
SPO-15 Beryoza [L-006] - (Su-24MP, An-12PP) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
TFR [Relyef] - (Su-24M) Radar
TFR, Terrain Following Radar
Max Range: 3.7 km
Weapons / Loadouts:
AA-8 Aphid [R-60TM] - (1983) Guided Weapon
Air Max: 9.3 km.
3000 liter Drop Tank - Drop Tank
