General data:
Type: Attack Crew: 2
Min Speed: 350 kt Max Speed: 920 kt
Wingspan: 21.3 m Height: 6.1 m
Length: 22.4 m Max Payload: 17000 kg
Empty Weight: 22725 kg Max Weight: 51756 kg
Operator: Air Force Commissioned: 1982
Propulsion: 2x TF30-PW-7
Sensors / EW:
AN/APQ-134 - (FB-111A) Radar
TFR, Terrain Following Radar
Max Range: 3.7 km
AN/ALQ-137 SPS - (Assoc w AN/ALR-62) ECM
DECM, Defensive ECM
Max Range: 0 km
AN/AAR-34 - (Assoc w AN/ALR-62) Infrared
MAWS, Missile Approach Warning System
Max Range: 9.3 km
AN/APQ-114 - (FB-111A) Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Short-Range
Max Range: 74.1 km
AN/ALR-62 TTWS Compass Sail - (FB-111A) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Weapons / Loadouts:
600 USG Drop Tank - Drop Tank
AGM-69A SRAM [200kT Nuclear] - (1973-1993) Guided Weapon
Land Max: 203.7 km.
B43 Strategic Bomb [1mT Nuclear] - (1962-1991) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
B61 Tactical/Strategic Bomb [340kT Nuclear] - (1968) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk82 500lb LDGP - (1954) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk82 500lb Snakeeye - (USN: 1967, USAF: 1970, Retarded) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk84 2000lb LDGP - (1955) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
CBU-52/B CB [217 x BLU-61/B Frag Bomblets] - (1972, SUU-30/B) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
CBU-58A/B CB [650 x BLU-63/B Frag Bomblets] - (1973, SUU-30/B) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
CBU-71A/B CB [650 x BLU-86/B Frag Bomblets] - (SUU-30A/B) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
