General data:
Type: Fighter Crew: 2
Min Speed: 350 kt Max Speed: 925 kt
Wingspan: 14.7 m Height: 5.9 m
Length: 21.9 m Max Payload: 8000 kg
Empty Weight: 16300 kg Max Weight: 30450 kg
Operator: Air Force Commissioned: 2013
Propulsion: 2x AL-31FM-1
Sensors / EW:
OLS-27 [IRST] - (Izdeliye 36Sh) Infrared
IRST, Imaging Infrared Seach and Track
Max Range: 100 km
L-175V Khibiny-10V - (Su-34) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
L-175V Khibiny-10V [KS-418] - (Su-34, Pod, Related to MSP-418K) ECM
DECM, Defensive ECM
Max Range: 0 km
Slot Back [N-001V Mech] - (Su-27SM) Radar
Radar, FCR, Air-to-Air, Long-Range
Max Range: 296.3 km
OLS-27 [Laser Rangefinder] - (Su-27SM) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
Weapons / Loadouts:
AA-10 Alamo A [R-27R, MR SARH] - (1984) Guided Weapon
Air Max: 83.3 km.
AA-11 Archer [R-73M] - (1998, HMS) Guided Weapon
Air Max: 18.5 km.
AA-10 Alamo C [R-27RE, LR SARH] - (1987) Guided Weapon
Air Max: 129.6 km.
AS-14 Kedge [Kh-29T] - (1985) Guided Weapon
Surface Max: 11.1 km. Land Max: 11.1 km.
BetAB-500SP CB [12 x Anti-Runway Penetrator Bomblets] - Bomb
Land Max: 1.9 km.
FAB-100M-62 GPB - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
FAB-250M-54 GPB - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
FAB-250M-62 GPB - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
FAB-500M-54 GPB - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
FAB-500M-62 GPB - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
KAB-1500Kr TV/EO - Guided Weapon
Surface Max: 3.7 km. Land Max: 3.7 km.
KAB-500Kr TV/EO - Guided Weapon
Surface Max: 3.7 km. Land Max: 3.7 km.
OFAB-100-120 Frag - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
OFAB-250-270 Frag - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
RBK-250-PTAB CB [30 x PTAB-2.5 Anti-Tank Bomblets] - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
RBK-500-PTAB CB [268 x PTAB-1M Anti-Tank Bomblets] - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
S-13B 122mm Rocket [Penetrator] - (1984) Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
S-24B 240mm Rocket - Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
S-5K 57mm Rocket - Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
S-8KO 80mm Rocket [HEAT] - (1985) Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
RBK-500-ZAB [117 x ZAB-2.5SM Incendiary] - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
KAB-1500Kr-Pr TV/EO [Penetrator] - Guided Weapon
Surface Max: 3.7 km. Land Max: 3.7 km.
AA-10 Alamo B [R-27T, MR IR] - (1984?) Guided Weapon
Air Max: 83.3 km.
AA-10 Alamo D [R-27TE, LR IR] - (1987) Guided Weapon
Air Max: 129.6 km.
