General data:
Type: Attack Crew: 1
Min Speed: 350 kt Max Speed: 925 kt
Wingspan: 8.4 m Height: 4.5 m
Length: 15.3 m Max Payload: 0 kg
Empty Weight: 7400 kg Max Weight: 16200 kg
Operator: Air Force Commissioned: 2013
Propulsion: 1x Atar 9K-50 Decommissioned: 2014
Sensors / EW:
Cyrano IV-MR - Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Medium-Range
Max Range: 111.1 km
Generic Visual Reconnaissance Camera - (4x Magnification) Visual
Visual, Reconnaissance Frame Camera
Max Range: 9.3 km
Type BF - (4x Magnification) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Weapons / Loadouts:
Barax NG DECM Pod - (AAM Rail) Sensor Pod
Omera 40 Recon Pod [Visual] - (France) Sensor Pod
1200 liter Drop Tank - Drop Tank
Phimat Chaff Pod - (1979) Sensor Pod
Rafael Recon Pod [SLAR] - (France) Sensor Pod
ASTAC Pod [ESM] - Sensor Pod
2200 liter Drop Tank - Drop Tank
R.550 Magic 2 Mk2 - (1997) Guided Weapon
Air Max: 18.5 km.
Atlis Pod [EO + LRMTS, 12k ft] - (1980) Sensor Pod
AS.30L - (1989) Guided Weapon
Surface Max: 11.1 km. Land Max: 11.1 km.
BGL-400 LGB - (1986, 1700 built) Guided Weapon
Surface Max: 7.4 km. Land Max: 7.4 km.
SNEB 68mm Rocket - (TDA 68mm, TBA 68 mm) Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
T.200 400kg GPB - (France) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
T.25 250kg GPB - (France) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
GBU-12D/B Paveway II LGB [Mk82] - Guided Weapon
Surface Max: 7.4 km. Land Max: 7.4 km.
