General data:
Type: Fighter Crew: 1
Min Speed: 350 kt Max Speed: 920 kt
Wingspan: 9.5 m Height: 4.7 m
Length: 14.3 m Max Payload: 3400 kg
Empty Weight: 6586 kg Max Weight: 12383 kg
Operator: Air Force Commissioned: 2015
Propulsion: 1x RD-93
Sensors / EW:
China KLJ-7 [Type 1478] - (JF-17) Radar
Radar, FCR, Air-to-Air, Medium-Range
Max Range: 111.1 km
China BM/KJ-8602A [SPS-1000] - (RW 1045) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Weapons / Loadouts:
1200 liter Drop Tank - Drop Tank
PL-9 - (1992, AAM) Guided Weapon
Air Max: 14.8 km.
800 liter Drop Tank - Drop Tank
250kg GPB - (Generic) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
500kg GPB - (Generic) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
PL-12 - (2004) Guided Weapon
Air Max: 92.6 km.
YJ-83K [C-802AK] - (Aircraft) Guided Weapon
Surface Max: 185.2 km.
CM-400AKG Wrecker [ASM, YJ-12 Derivative] - (2015) Guided Weapon
Surface Max: 250 km.
LT-2 LGB [LS-500J, 500kg HE] - (China) Guided Weapon
Surface Max: 7.4 km. Land Max: 7.4 km.
K/JDC-01A Blue Sky Pod [FLIR + LRMTS, 12k ft] - (China) Sensor Pod
LS-6-500 Extended-Range Bomb, GPS/INS [500kg HE] - (China, 2010?) Guided Weapon
Land Max: 55.6 km.
MAR-1 [ARM] - Guided Weapon
Surface Max: 59.3 km. Land Max: 59.3 km.
China Type 200-4 [Durandal Copy] - (1997) Bomb
Land Max: 1.9 km.
H-4 SOW [Raptor 2] - (South Africa / Pakistan, 2003) Guided Weapon
Surface Max: 111.1 km. Land Max: 111.1 km.
H-4 SOW [Raptor 2] Datalink Pod - (South Africa / Pakistan) Sensor Pod
