| General data: | |
|---|---|
| Type: Tanker (Air Refueling) | Crew: 5 |
| Min Speed: 120 kt | Max Speed: 360 kt |
| Wingspan: 40.4 m | Height: 11.8 m |
| Length: 29.8 m | Max Payload: 19050 kg |
| Empty Weight: 34275 kg | Max Weight: 79380 kg |
| Operator: Marine Corps | Commissioned: 2010 |
| Propulsion: 4x Rolls-Royce AE 2100D3 |
| Sensors / EW: |
|---|
| AN/AAR-47A(V)2 - (2007) Infrared MAWS, Missile Approach Warning System Max Range: 9.3 km |
| AN/ALQ-157A(V)1 - (2007) ECM IRCM Max Range: 0 km |
| AN/APR-39(V)2 - (USN/USMC) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| AN/APN-241 [MR-3000] - (2008) Radar Radar, Weather and Navigation Max Range: 92.6 km |
| AN/AAQ-30 Hawkeye TSS [TV] - (2008) Visual Visual, Weapon Director & Target Search, Tracking and Identification TV Camera Max Range: 111.1 km |
| AN/AAQ-30 Hawkeye TSS [IR Camera] - (2008) Infrared Infrared, Weapon Director & Target Search, Tracking and Identification Camera Max Range: 55.6 km |
| Generic Laser Designator - (Anti-Air & Surface) Laser Designator Laser Target Designator & Ranger (LTD/R) Max Range: 18.5 km |
| Generic Laser Designator - (Surface Only) Laser Designator Laser Target Designator & Ranger (LTD/R) Max Range: 18.5 km |
| Weapons / Loadouts: |
|---|
| AGM-114P Hellfire II -
(2006) Guided Weapon Surface Max: 9.3 km. Land Max: 9.3 km. |
| AGM-176A Griffin A -
Guided Weapon Surface Max: 22.2 km. Land Max: 22.2 km. |
| 3600 USG Ferry Tank -
(KC-130J) Ferry Tank |
| GBU-44/B Viper Strike -
(USAF, 2005, BAT) Guided Weapon Surface Max: 3.7 km. Land Max: 3.7 km. |
| AN/ALQ-231(V)1 Intrepid Tiger II -
(IT II, AV-8B, F-18) Sensor Pod |
