General data:
Type: Fighter Crew: 1
Min Speed: 350 kt Max Speed: 1150 kt
Wingspan: 6.4 m Height: 4.1 m
Length: 16.7 m Max Payload: 1995 kg
Empty Weight: 6350 kg Max Weight: 13170 kg
Operator: Air Force Commissioned: 1978
Propulsion: 1x J79-GE-11A Decommissioned: 1986
Sensors / EW:
NASAAR F-15A-41-B - (F-104G) Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Short-Range
Max Range: 29.6 km
CA/ALR-501 - (F-104G, Similar to AN/ALR-47) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Weapons / Loadouts:
170 USG Drop Tank - Drop Tank
195 USG Drop Tank - Drop Tank
Mk82 500lb LDGP - (1954) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk83 1000lb LDGP - (1954) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk82 500lb Snakeeye - (USN: 1967, USAF: 1970, Retarded) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
BL.755 No.1 CB [147 x GP Anti-Armor Bomblets] - (1973) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
CRV-7 C14 70mm Rocket - (1976) Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
