General data:
Type: Attack Crew: 2
Min Speed: 55 kt Max Speed: 180 kt
Wingspan: 4.3 m Height: 4.2 m
Length: 13.9 m Max Payload: 0 kg
Empty Weight: 5540 kg Max Weight: 8390 kg
Operator: Marine Corps Commissioned: 2012
Propulsion: 2x T700-GE-401
Sensors / EW:
AN/AVR-2 - ESM
LWR, Laser Warning Receiver
Max Range: 18.5 km
AN/AAR-47A(V)2 - (2007) Infrared
MAWS, Missile Approach Warning System
Max Range: 9.3 km
AN/ALQ-144A(V)1 - (2007) ECM
IRCM
Max Range: 0 km
AN/APR-39B(V)2 - (USN/USMC) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
AN/AAQ-30 Hawkeye TSS - (USN/USMC) Infrared
Infrared, Weapon Director & Target Search, Tracking and Identification Camera
Max Range: 55.6 km
Generic Laser Designator - (Surface Only) Laser Designator
Laser Target Designator & Ranger (LTD/R)
Max Range: 18.5 km
Weapons / Loadouts:
HYDRA 70mm Rocket - Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
AIM-9M Sidewinder - (1984) Guided Weapon
Air Max: 18.5 km.
AGM-114K Hellfire II - Guided Weapon
Surface Max: 9.3 km. Land Max: 9.3 km.
HYDRA APKWS II 70mm Rocket [WGU-59/B] - (2012) Guided Weapon
Surface Max: 3.7 km. Land Max: 3.7 km.
