General data:
Type: Attack Crew: 2
Min Speed: 55 kt Max Speed: 160 kt
Wingspan: 4.9 m Height: 4.9 m
Length: 14.96 m Max Payload: 0 kg
Empty Weight: 5360 kg Max Weight: 10450 kg
Operator: Army Commissioned: 2008
Propulsion: 2x T700-GE-701C
Sensors / EW:
AN/APG-78 Longbow MMR - Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Short-Range
Max Range: 37 km
AN/AAQ-11 PNVS - (Assoc w AN/ASQ-170) Infrared
Infrared, Weapon Director & Target Search, Tracking and Identification FLIR
Max Range: 55.6 km
Sky Guardian 2000 - (Assoc w AN/ASQ-170) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
AN/AAR-57 CMWS - (Common Missile Warning System) Infrared
MAWS, Missile Approach Warning System
Max Range: 9.3 km
ASQ-170 TADS/PNVS - (Common Missile Warning System) Visual
LLTV, Weapon Director & Target Search, Tracking and Identification
Max Range: 55.6 km
Generic Laser Designator - (Surface Only) Laser Designator
Laser Target Designator & Ranger (LTD/R)
Max Range: 18.5 km
Type 1223 - (SELEX Galileo) ESM
LWR, Laser Warning Receiver
Max Range: 11.1 km
Weapons / Loadouts:
230 USG Drop Tank - Drop Tank
AGM-114KBF Hellfire II - Guided Weapon
Surface Max: 9.3 km. Land Max: 9.3 km.
HYDRA 70mm Rocket - Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
