General data:
Type: Anti-Submarine Warfare (ASW) Crew: 4
Min Speed: 180 kt Max Speed: 440 kt
Wingspan: 20.9 m Height: 6.9 m
Length: 16.3 m Max Payload: 0 kg
Empty Weight: 12060 kg Max Weight: 23830 kg
Operator: Navy Commissioned: 1984
Propulsion: 2x TF34-GE-2
Sensors / EW:
AN/APS-116 - Radar
Radar, Surface Search, Medium-Range
Max Range: 277.8 km
AN/ALR-47 - (CA/ALR-502) ESM
ELINT
Max Range: 926 km
OR-89/AA - (CA/ALR-502) Infrared
Infrared, Surveillance FLIR
Max Range: 55.6 km
AN/ASQ-81(V)3 - (S-3A) MAD
MAD
Max Range: 1.9 km
Weapons / Loadouts:
300 USG Drop Tank - Drop Tank
Mk46 LWT Mod 2 - (1972) Torpedo
Subsurface Max: 5.6 km.
AN/SSQ-53A DIFAR - (A-Size, 31 Chn, 27m/304m) Sonobuoy
AN/SSQ-62A DICASS - (1979, A-Size, 31 Chn, 27/457m, 1hr) Sonobuoy
Mk46 NEARTIP Mod 5 - (1984) Torpedo
Subsurface Max: 7.4 km.
Mk82 500lb LDGP - (1954) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
ZUNI 127mm HVAR Rocket - Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
HYDRA 70mm Rocket - Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
Mk83 1000lb LDGP - (1954) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk84 2000lb LDGP - (1955) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk62 Quickstrike [Mk82] - (1982) Bottom Mine
Mk63 Quickstrike [Mk83] - (1982) Bottom Mine
Mk65 Mod 0 Quickstrike [2000lb] - (1984, 90m max depth) Bottom Mine
Mk52 [1000lb] - (1962) Bottom Mine
Mk55 [2000lb] - (1962, 180m max depth) Bottom Mine
B57 Multipurpose Sub Bomb [20kT Nuclear] - (Aerial) Depth Charge
Subsurface Max: 0.9 km.
Mk82 500lb Snakeeye - (USN: 1967, USAF: 1970, Retarded) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk20 Rockeye II CB [247 x Mk118 Dual Purpose Bomblets] - (1969, Mk7 Dispenser) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
CBU-59/B APAM [717 x BLU-77/B Dual-Purpose Bomblets] - (Mk7 Dispenser) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
CBU-78/B GATOR [45 x BLU-91/B Bomblets + 15 x BLU-92/B Mines] - (Mk7 Dispenser) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
