General data:
Type: Attack Crew: 2
Min Speed: 350 kt Max Speed: 750 kt
Wingspan: 12.8 m Height: 6.2 m
Length: 22.3 m Max Payload: 9000 kg
Empty Weight: 13500 kg Max Weight: 30000 kg
Operator: Navy Commissioned: 2008
Propulsion: 2x WS-9/Spey Mk.202
Sensors / EW:
China JL-10A Shen Ying - (JH-7A) Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Short-Range
Max Range: 83.3 km
China BM/KG-8605 - (JH-7A) ECM
DECM, Defensive ECM
Max Range: 0 km
China BM/KJ-8602 [SPS-1000] - (RW 1045) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Generic Laser Designator - (Surface Only) Laser Designator
Laser Target Designator & Ranger (LTD/R)
Max Range: 18.5 km
Generic LLTV - (2nd Gen, Target Tracking And Identification) Visual
LLTV, Target Tracking and Identification
Max Range: 148.2 km
Weapons / Loadouts:
PL-8A [Python 3] - (1991, AAM) Guided Weapon
Air Max: 14.8 km.
YJ-83K [C-802AK] - (Aircraft) Guided Weapon
Surface Max: 185.2 km.
1400 liter Drop Tank - Drop Tank
China KG-300 DECM pod - Sensor Pod
250kg GPB - (Generic) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
500kg GPB - (Generic) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
57mm Rocket - (Generic) Rocket
Surface Max: 1.9 km. Land Max: 1.9 km.
90mm Rocket - (Generic) Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
AS-17 Krypton C [Kh-31P, ARM] - Guided Weapon
Surface Max: 111.1 km. Land Max: 111.1 km.
LT-2 LGB [LS-500J, 500kg HE] - (China) Guided Weapon
Surface Max: 7.4 km. Land Max: 7.4 km.
K/JDC-01A Blue Sky Pod [FLIR + LRMTS, 12k ft] - (China) Sensor Pod
Generic Mine [Bottom, Acoustic Narrow-Band Fuze & Target Discrimination] - (Advanced) Bottom Mine
KD-88 LACM - (C-803/YJ-83 LACM, C-802AKG) Guided Weapon
Surface Max: 185.2 km. Land Max: 185.2 km.
LS-6-500 Extended-Range Bomb, GPS/INS [500kg HE] - (China, 2010?) Guided Weapon
Land Max: 55.6 km.
China Type 200-4 [Durandal Copy] - (1997) Bomb
Land Max: 1.9 km.
