General data:
Type: Fighter Crew: 1
Min Speed: 350 kt Max Speed: 925 kt
Wingspan: 8.3 m Height: 4.1 m
Length: 14.0 m Max Payload: 0 kg
Empty Weight: 4871 kg Max Weight: 8625 kg
Operator: Air Force Commissioned: 2005
Propulsion: 1x WP-13F [R-13F-300 Copy]
Sensors / EW:
China BM/KG-8605 - ECM
DECM, Defensive ECM
Max Range: 0 km
China BM/KJ-8602 [SPS-1000] - (RW 1045) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
China KLJ-6E Lieying - (EL/M-2001 / Pointer 2500) Radar
Radar, Range-Only (RO)
Max Range: 14.8 km
Weapons / Loadouts:
PL-8A [Python 3] - (1991, AAM) Guided Weapon
Air Max: 14.8 km.
720 liter Drop Tank - Drop Tank
480 liter Drop Tank - Drop Tank
250kg GPB - (Generic) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
500kg GPB - (Generic) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
57mm Rocket - (Generic) Rocket
Surface Max: 1.9 km. Land Max: 1.9 km.
90mm Rocket - (Generic) Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
