General data:
Type: Fighter Crew: 1
Min Speed: 350 kt Max Speed: 1000 kt
Wingspan: 14.0 m Height: 6.0 m
Length: 23.0 m Max Payload: 4500 kg
Empty Weight: 16500 kg Max Weight: 38000 kg
Operator: Air Force Commissioned: 2018
Propulsion: 2x WS-15
Sensors / EW:
China BM/KJ 8602C - (RW 1045) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
J-20 AESA - (Type 1475/KLJ5?, LPI) Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Medium-Range
Max Range: 222.2 km
Generic DECM [Advanced] - (1990s) ECM
DECM, Defensive ECM
Max Range: 0 km
Generic IRST - (3rd Gen Imaging) Infrared
IRST, Imaging Infrared Seach and Track
Max Range: 185.2 km
Generic Laser Rangefinder - (Anti-Air & Surface) Laser Rangefinder
Laser Rangefinder
Max Range: 7.4 km
China EO-DAS MAWS - (J-20) Infrared
MAWS, Missile Approach Warning System
Max Range: 9.3 km
China EO-DAS - (J-20) Infrared
Infrared, Day/Night Spherical Situational Awareness & Fire Control
Max Range: 111.1 km
Weapons / Loadouts:
PL-12C - (2018+, Folding fins for J-20) Guided Weapon
Air Max: 92.6 km.
PL-10 - (2018) Guided Weapon
Air Max: 20 km.
1700 liter Drop Tank - Drop Tank
LS-6-500 Extended-Range Bomb, GPS/INS [500kg HE] - (China, 2010?) Guided Weapon
Land Max: 55.6 km.
YJ-91 [Kh-31P, ARM] - Guided Weapon
Surface Max: 111.1 km. Land Max: 111.1 km.
PL-15 - (2018+) Guided Weapon
Air Max: 174.1 km.
