General data:
Type: Wild Weasel Crew: 2
Min Speed: 350 kt Max Speed: 920 kt
Wingspan: 11.7 m Height: 5.02 m
Length: 19.2 m Max Payload: 8480 kg
Empty Weight: 13755 kg Max Weight: 28030 kg
Operator: Air Force Commissioned: 1988
Propulsion: 2x J79-GE-17
Sensors / EW:
AN/APQ-120 - (F-4E) Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Medium-Range
Max Range: 111.1 km
AN/APR-47 RHAWS - (F-4E) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Weapons / Loadouts:
AGM-45B Shrike [ARM] - (1975-1992) Guided Weapon
Surface Max: 46.3 km. Land Max: 46.3 km.
AN/ALQ-131 DECM Pod - (1983?) Sensor Pod
AIM-7F Sparrow III - (1977) Guided Weapon
Air Max: 101.9 km.
600 USG Drop Tank - Drop Tank
AGM-88A HARM - (USN 1986, USAF 1988) Guided Weapon
Surface Max: 129.6 km. Land Max: 129.6 km.
370 USG Drop Tank - Drop Tank
AGM-65B Maverick EO - (1976) Guided Weapon
Surface Max: 11.1 km. Land Max: 11.1 km.
AGM-65D Maverick IR - (1984) Guided Weapon
Surface Max: 14.8 km. Land Max: 14.8 km.
