General data:
Type: Maritime Patrol Aircraft (MPA) Crew: 10
Min Speed: 205 kt Max Speed: 410 kt
Wingspan: 30.4 m Height: 10.3 m
Length: 35.6 m Max Payload: 9070 kg
Empty Weight: 27890 kg Max Weight: 61235 kg
Operator: Air Force Commissioned: 2002
Propulsion: 4x T56-A-14
Sensors / EW:
EL/M-2022A(V)3 - Radar
Radar, Surface Search, Long-Range
Max Range: 370.4 km
AN/ALQ-157 - (1985, Matador) ECM
IRCM
Max Range: 0 km
AN/AAS-36 IRDS - (P-3C Update II) Infrared
Infrared, Surveillance FLIR
Max Range: 55.6 km
EL/ALR-2001 Odyssey - (Australia, P-3, OTH Harpoon Targeting, L-8300) ESM
ELINT
Max Range: 926 km
CA/ASQ-504(V) AIMS - (Australia, P-3, OTH Harpoon Targeting, L-8300) MAD
MAD
Max Range: 1.9 km
Weapons / Loadouts:
AGM-84D Harpoon IC - (1986) Guided Weapon
Surface Max: 138.9 km.
Mk46 NEARTIP Mod 5 - (1984) Torpedo
Subsurface Max: 7.4 km.
AN/SSQ-62C DICASS - (1997-2002, A-Size, 86 Chn, 27/121/457m) Sonobuoy
AN/SSQ-53F DIFAR - (2002, A-Size, 99 Chn, 27/60/121/304m, 0.5/1/2/4/8hrs) Sonobuoy
SSQ-801B Barra - (1997, 99 Chn, 22/129m, 0.5/1/2/4) Sonobuoy
