General data:
Type: Fighter Crew: 2
Min Speed: 350 kt Max Speed: 1350 kt
Wingspan: 13.5 m Height: 6.2 m
Length: 22.7 m Max Payload: 5000 kg
Empty Weight: 21825 kg Max Weight: 46200 kg
Operator: Air Force Commissioned: 1992
Propulsion: 2x D-30F6
Sensors / EW:
IRST [8TP] - (MiG-31) Infrared
IRST, Imaging Infrared Seach and Track
Max Range: 148.2 km
Flash Dance [N-007 Zaslon] - (MiG-31) Radar
Radar, FCR, Air-to-Air, Long-Range
Max Range: 314.8 km
SPS-171/172 Sorbtsiya [L-005] - (MiG-31) ECM
DECM, Defensive ECM
Max Range: 0 km
SPO-15 Beryoza [L-006] - (MiG-31) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Weapons / Loadouts:
AA-9 Amos [R-33, SARH] - Guided Weapon
Air Max: 166.7 km.
2500 liter Drop Tank - Drop Tank
AA-8 Aphid [R-60TM] - (1983) Guided Weapon
Air Max: 9.3 km.
AA-6 Acrid F [R-40TD1, IR] - (1988) Guided Weapon
Air Max: 83.3 km.
