General data:
Type: Bomber Crew: 6
Min Speed: 280 kt Max Speed: 510 kt
Wingspan: 56.4 m Height: 12.4 m
Length: 48.5 m Max Payload: 0 kg
Empty Weight: 81730 kg Max Weight: 221550 kg
Operator: Air Force Commissioned: 1975
Propulsion: 8x J57-P-43WB
Sensors / EW:
AN/ASQ-176 OAS - Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Short-Range
Max Range: 74.1 km
AN/ALT-32L - (Low-Band Jamming Set, Phase V ECM) ECM
OECM, Offensive ECM
Max Range: 0 km
AN/ALT-32H - (High-Band Jamming Set, Phase V ECM) ECM
OECM, Offensive ECM
Max Range: 0 km
AN/ALT-16A [AN/ALQ-122 SNOE] - (Barrage Jamming System, Phase VI ECM) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
AN/ALR-46(V) - (Digital Radar Warning Receivert, Phase VI ECM Fit) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
AN/ALT-28 [AN/ALQ-155] - (Noise Jammer, Phase VI ECM Fit) ECM
OECM, Offensive ECM
Max Range: 0 km
AN/ALQ-117 - (Electronic Countermeasures System, Phase VI ECM Fit) ECM
DECM, Defensive ECM
Max Range: 0 km
AN/AVQ-22 LLTV [AN/ASQ-151 EVS] - (Electronic Countermeasures System, Phase VI ECM Fit) Visual
LLTV, Navigation & Attack
Max Range: 27.8 km
AN/AAQ-6 FLIR [AN/ASQ-151 EVS] - (Electronic Countermeasures System, Phase VI ECM Fit) Infrared
Infrared, Navigation / Attack FLIR
Max Range: 27.8 km
AN/ALQ-153 - (Phase IV) Radar
TWR, Tail Warning Radar & Tail Gun Director
Max Range: 18.5 km
AN/ALR-20A - (Panoramic Receiver Set, Phase VI ECM Fit) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Generic Tail Gun Director [TV Camera] - (1st Gen) Visual
Visual, Weapon Director TV Camera
Max Range: 74.1 km
Weapons / Loadouts:
AGM-69A SRAM [200kT Nuclear] - (1973-1993) Guided Weapon
Land Max: 203.7 km.
B28 Strategic Bomb [1.45mT Nuclear] - (1958-1991) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk82 500lb LDGP - (1954) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk84 2000lb LDGP - (1955) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
M117 750lb GPB - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk55 [2000lb] - (1962, 180m max depth) Bottom Mine
