General data:
Type: Attack Crew: 2
Min Speed: 55 kt Max Speed: 160 kt
Wingspan: 5.2 m Height: 4.6 m
Length: 14.96 m Max Payload: 0 kg
Empty Weight: 5165 kg Max Weight: 10450 kg
Operator: Army Commissioned: 1987
Propulsion: 2x T700-GE-701
Sensors / EW:
AN/AAQ-11 PNVS - (Assoc w AN/ASQ-170) Infrared
Infrared, Weapon Director & Target Search, Tracking and Identification Camera
Max Range: 55.6 km
AN/ALQ-136(V)5 - (Assoc w AN/ASQ-170) ECM
DECM, Defensive ECM
Max Range: 0 km
AN/ALQ-144 - (Assoc w AN/ASQ-170) ECM
IRCM
Max Range: 0 km
ASQ-170 TADS/PNVS - (Assoc w AN/ASQ-170) Visual
LLTV, Weapon Director & Target Search, Tracking and Identification
Max Range: 55.6 km
Generic Laser Designator - (Surface Only) Laser Designator
Laser Target Designator & Ranger (LTD/R)
Max Range: 18.5 km
AN/APR-39A(V)1 - (Army) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Weapons / Loadouts:
AGM-114A Hellfire - Guided Weapon
Surface Max: 7.4 km. Land Max: 7.4 km.
HYDRA 70mm Rocket - (Mk 66 Rocket, M229 Warhead, M423/7 Fuze) Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
230 USG Drop Tank - Drop Tank
