General data:
Type: Maritime Patrol Aircraft (MPA) Crew: 10
Min Speed: 205 kt Max Speed: 410 kt
Wingspan: 30.4 m Height: 10.3 m
Length: 35.6 m Max Payload: 9070 kg
Empty Weight: 27890 kg Max Weight: 61235 kg
Operator: Navy Commissioned: 1997
Propulsion: 4x T56-A-14 Decommissioned: 2003
Sensors / EW:
AN/ALQ-157 - (1985, Matador) ECM
IRCM
Max Range: 0 km
AN/APS-115 - (1985, Matador) Radar
Radar, Surface Search, Long-Range
Max Range: 370.4 km
AN/AAS-36 IRDS - (P-3C Update II) Infrared
Infrared, Surveillance FLIR
Max Range: 55.6 km
AN/ALR-66A(V)3 - (P-3C) ESM
ELINT w/ OTH Targeting
Max Range: 926 km
AN/ASQ-81(V)1 - (P-3C) MAD
MAD
Max Range: 1.9 km
Weapons / Loadouts:
Mk46 NEARTIP Mod 5A(SW) - (1997) Torpedo
Subsurface Max: 7.4 km.
AN/SSQ-53D DIFAR - (1992, A-Size, 99 Chn, 27/121/304m, 0.5/1/2/4/8hrs) Sonobuoy
AN/SSQ-77B VLAD - (1994, A-Size, 99 Chn, 152/305m, 1/4/8hrs) Sonobuoy
AN/SSQ-62C DICASS - (1997-2002, A-Size, 86 Chn, 27/121/457m) Sonobuoy
AGM-84G Harpoon ICR - (1998) Guided Weapon
Surface Max: 138.9 km.
Mk50 Barracuda Mod 0 ALWT - (1991) Torpedo
Subsurface Max: 7.4 km.
Mk52 [1000lb] - (1962) Bottom Mine
Mk55 [2000lb] - (1962, 180m max depth) Bottom Mine
Mk62 Quickstrike [Mk82] - (1982) Bottom Mine
Mk65 Mod 0 Quickstrike [2000lb] - (1984, 90m max depth) Bottom Mine
Mk63 Quickstrike [Mk83] - (1982) Bottom Mine
Mk60 CAPTOR [Encapsulated Torpedo] - (1981) Rising Mine
Subsurface Max: 2.8 km.
