General data:
Type: Area Surveillance Crew: 3
Min Speed: 180 kt Max Speed: 295 kt
Wingspan: 16.61 m Height: 4.5 m
Length: 13.34 m Max Payload: 0 kg
Empty Weight: 3520 kg Max Weight: 7250 kg
Operator: Army Commissioned: 1996
Propulsion: 2x PT6A-67D
Sensors / EW:
AN/APR-44 - (Continuous-Wave RWR) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
AN/ALQ-136(V)2 - (Pulse-Radar Jammer) ECM
DECM, Defensive ECM
Max Range: 0 km
Generic ESM [Advanced] - (1990s, Precise Emitter ID) ESM
ELINT
Max Range: 926 km
AN/APR-39(V)1 - (Army) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
AN/ALQ-156 - (Army) Infrared
MAWS, Missile Approach Warning System
Max Range: 9.3 km
AN/ALQ-162 Shadowbox - (Wontinuous-Wave-Radar Jammer) ECM
DECM, Defensive ECM
Max Range: 0 km
