General data:
Type: Fighter Crew: 2
Min Speed: 350 kt Max Speed: 920 kt
Wingspan: 19.6 m Height: 4.9 m
Length: 19.1 m Max Payload: 5900 kg
Empty Weight: 18110 kg Max Weight: 32098 kg
Operator: Navy Commissioned: 1986
Propulsion: 2x TF30-PW-414A
Sensors / EW:
AN/ALQ-126A - ECM
DECM, Defensive ECM
Max Range: 0 km
AN/AWG-9 - Radar
Radar, FCR, Air-to-Air, Long-Range
Max Range: 333.4 km
AN/ALR-50 Charger Blue - (Navy) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
AN/ALR-45 Compass Tie - (Navy) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
AN/AXX-1 TCS - (Navy) Visual
Visual, Target Search, Slaved Tracking and Identification TV Camera
Max Range: 185.2 km
Weapons / Loadouts:
AIM-7M Sparrow III - (1985) Guided Weapon
Air Max: 101.9 km.
267 USG Drop Tank - Drop Tank
AIM-9M Sidewinder - (1984) Guided Weapon
Air Max: 18.5 km.
AIM-54A Phoenix - (1974) Guided Weapon
Air Max: 185.2 km.
LA-610 TARPS Pod [IR + EO] - Sensor Pod
Open Description
